Specs:
| SKU | SKU-MKS-DS95i | |
| Dead Band | 0.001ms (Default) | |
| Control System | Pulse Width Control | |
| Working Frequence | 760μs / 560hz | |
| (RX) Required Pulse | 3.0~5.0 Volt Peak to Peak Square Wave | |
| Operating Voltage | 4.8~6.0 V DC Volts | |
| Operating Temperature Range | -10 to 60 Degree C | |
| Operating Speed (4.8V) | 0.047 sec/60° degrees at no load | |
| Operating Speed (6V) | 0.038 sec/60° dagrees at no load | |
| Stall Torque (4.8V) | 1.92 kg-cm (26.66 oz/in) | |
| Stall Torque (6V) | 2.40 kg-cm (33.33oz/in) | |
| 360° Modifiable | YES | |
| Motor Type | Coreless Motor | |
| Potentiometer Drive | Direct Drive | |
| Driver Type | FET | |
| Bearing Type | Dual Ball Bearings | |
| Gear Type | Chrome-Titanium alloy gear | |
| Programmable | NO | |
| Connector Wire Length | 20.0 cm (7.86 in) | |
| Dimensions | 23X12X27.25 mm (0.9X0.47X1.07 in) | |
| Weight | 21.21 g (0.74 oz) | |
